PIN-LOCKING ARM

• No port or starboard designation
• Underside locking pin connection
• Arm lifts up to 46.5º from horizontal position for kite fishing and dock clearance
• Pairs with 1-1/2" DIA Outrigger Poles up to 22'
• Can be used with Outrigger Base Reducer for 1-1/8” DIA poles

HANDLE

• Stainless-steel, ergonomic, single-hand crank handle with ball bearing
• Enables lift and rotation of outrigger poles from safety of the deck
• Unique, locking flip handle
  •   Keeps the handle knob on the bottom when lifting or rotating the outrigger
  •   Provides full torque control and safety of deployment at all times
• Robust, dual-detented lifting crank handle locks flush into base

MOUNT

• Made for hardtops up to 4-1/2" thick
• Ideal for boats 25' to 40'
• Constructed from cast stainless-steel and machined aluminum for a stronger, lighter base
• Each mount weighs 15 pounds (30 pounds per pair)
• Safety detents prevent uncontrolled rotation when deploying outrigger poles
• Allows a controlled 180° rotation, if needed
• Locking head eliminates downward creep of outrigger poles
• Equipped to handle the torque and whip generated by poles up to 22’
• Includes mounting hardware for easy installation
• Base hole pattern matches all TACO Marine Grand Slam models, as well as the industry standard hole patterns of other top-mount outrigger systems
• Backing plates (BP-0300) sold separately
• 3-year limited warranty
